วาลว์ลมใช้มือปิด

The hand valves are designed to turn on and off the airflow.
TWo-way and three-way valves are available for all models.
Three-way directional control valve releases the residual internal pressure on the
Output side when manually closed
G-Thread type also available.

Fluid TypeAir (No other type of gas or liquid)
Working Pressure Range0~150PSI0~9.9KgF/cm2(0~990KPa)
Negative Pressure-29.5 in Hg-750mm Hg(10 Torr)
Working Temperature32~140°F0-60℃
- -
HVFFMODEL(φD-T)
       Tube(Metric)-Thread(R)
 HVFF 06-06
 HVFF 08-06
 HVFF 08-08
 HVFF 10-08
 HVFF 10-10
 HVFF 12-10
 HVFF 12-12
- - -
HVSFMODEL(φD-T)
       Tube(Metric)-Thread(R)
 HVSF 01-06 HVSF 02-12
 HVSF 02-06 HVSF 03-12
 HVSF 03-06 HVSF 04-12
 HVSF 01-08
 HVSF 02-08
 HVSF 03-08
 HVSF 02-10
 HVSF 03-10
 HVSF 04-10
- - -
HVFSMODEL(φD-T)
       Tube(Metric)-Thread(R)
 HVFS 06-01 HVFS 12-02
 HVFS 06-02 HVFS 12-03
 HVFS 06-03 HVFS 12-04
 HVFS 08-01
 HVFS 08-02
 HVFS 08-03
 HVFS 10-02
 HVFS 10-03
 HVFS 10-04
- - -
HVSSMODEL(φD-T)
       Tube(Metric)-Thread(R)
 HVSS 01-01
 HVSS 02-01
 HVSS 02-02
 HVSS 03-02
 HVSS 03-03
 HVSS 04-03
 HVSS 04-04

When you order two way valves,please put B at the end of model type.For example,HVFF06-06B
