EB-SYD EBRO ARMATUREN Pneumatic Actuator

EBRO ARMATUREN EB-SYD Pneumatic Actuator

Pneumatic Actuator EB-SYD, DOUBLE ACTING
The scotch-yoke principle in the EB actuators exactly matches the valve torque characteristics,thus reducing size and air consumption.

Actuator Technology
Something not many people know: EBRO produces its own actuators - and has been doing so for 30 years. For EBRO customers this means that butterfly and gate valves can always be equipped with the most suitable actuator. No compromises, just the best possible match of components - this is what the EBRO actuator series stands for.Pneumatic actuators, single or double acting, have been proven for decades. However, industrial process air is expensive. Energy efficiency is therefore the topic of the day. As a manufacturer of valves and actuators, EBRO can specifically match single product components according to customer requirements and within the scope of operating conditions, thus substantially reducing regular operating costs.

ยี่ห้อ EBRO จากประเทศเยอรมัน ตัวนี้เป็นรุ่นยอดฮิต มีทั้งแบบ wafer type และ lug type ใช้ได้กับงานหลายประเภท เช่น อุตสาหกรรมเคมีและปิโตรเคมี งานระบบน้ำประปา โรงบำบัดน้ำเสีย อุตสาหกรรมต่อเรือ มีหลายขนาดให้เลือก ทั่วไปคือ DN20-DN1200 รบกวนระบุขนาด และประเภทงาน ที่ต้องการใช้งาน

The double acting version of this series is available in 13 sizes,
constructed to the scotch-yoke principle.

FEATURES
- Maintenance-free
- Suitable for all 1 turn valves
- Blow-out proofed shaft
- Torques in agreement with EN ISO 5211
- Optical position indicator with integrated operator for limit switches
- All fasteners made of stainless steel
- SIL 2 (SIL 3 as redundant system) acc. to IEC 61508

KEY BENEFITS
- High opening- and closing- torques provided by scotch-yoke concept
- Ideal sliding properties provided by low friction multiple piston guides
- OperationaI safety and long service life assured by precise machining of parts
- Low air consumption
- ATEX: EX I1 2 GD c Tx
